C8-B/C12-B Service Manual Maintenance Disclosure Scope: Maintenance Trained Personnel Only
(C) Seiko Epson Corporation 2-172 Rev.1
2.7 Joint #5
2.7.1 Joint #5 Replacing the Timing Belt
S06: 7-M4x10
Arm4 Side Cover (left)
J5 Timing Belt
