1.2.5 Tools/Materials
Tools used
Name
Quantity
Note
Hexagonal wrench
width across flats: 1.5 mm
1
For M3 hexagon socket head set screws
width across flats: 2 mm
1
For M2.5 silver and black hexagon socket head cap screws, and for M4
hexagon socket head set screws
width across flats: 2.5 mm
1
For M3 silver and black hexagon socket head cap screws, and for M5
hexagon socket head set screws
width across flats: 3 mm
1
For M4 silver and black hexagon socket head cap screws
width across flats: 4 mm
1
For M5 silver and black hexagon socket head cap screws
width across flats: 5 mm
1
For M6 silver and black hexagon socket head cap screws
width across flats: 6 mm
1
For M8 silver and black hexagon socket head cap screws
Torque wrench
0.7 N·m to 44.0 N·m
1
For details, refer to 1.2.6 Tightening Bolts/Screws.
Phillips screwdriver
Ph2
1
For covers, and for securing the Ground Wires
Flat head screwdriver
1
For grease plug
Needle-nose pliers
1
For removing the Air Tubes
Feeler gauge (0.5 mm)
2
For adjusting the fixing position of the pulleys and Brake Hubs
Wrench
width across flats: 5 mm
1
2.9.1 Removing the Cable Unit (For removing the D-sub Connectors)
width across flats: 8 mm
1
For removing and installing the air tube fittings
Box wrench
width across flats: 5 mm
1
2.9.1 Removing the Cable Unit (For removing the D-sub Connectors)
Nipper
1
For cutting wire tie
Spatula
1
For applying grease on the Reduction Gear
Wiping cloth
1
For wiping grease from the Reduction Gear
Sonic Belt Tension Meter
1
3.1 Adjusting the Timing Belt Tension
Force gauge
1
3.1 Adjusting the Timing Belt Tension
Suitable cord (Length about 800 mm)
1
3.1 Adjusting the Timing Belt Tension
Cushioning or rags
1
To prevent the arms from being damaged
Grease up kit
(A set of grease gun, nipple, and extension jig)
1
Maintenance Parts Code: 1674592
