C8-B/C12-B Service Manual Maintenance Disclosure Scope: Maintenance Trained Personnel Only
(C) Seiko Epson Corporation 2-21 Rev.1
2.2.3 Joint #1 Replacing the Brake
J1 Brake
S06: 6-M4x10
S01: 11-M4x10
S01: 3-M4x20
Connector Plate
Base Maintenance Cover
J1 Brake Plate
S01: 3-M4x25
