C8-B/C12-B Service Manual Maintenance Information Disclosure Scope: Maintenance Trained Personnel Only
(C) Seiko Epson Corporation 1-34 Rev.1
1.4 Difference between M/C Cable Backward model and M/C Cable Downward model
1.4.1 Connector Plate
M/C Cable Backward model
M/C Cable Downward model
