C8-B/C12-B Service Manual Maintenance Disclosure Scope: Maintenance Trained Personnel Only
(C) Seiko Epson Corporation 2-94 Rev.1
2.5.2 Joint #3 Replacing the Motor Unit
S06: 4-M4x10
Timing Belt
Arm2 Side Cover
S01: 3-M4x20
and washer
Arm2 Side Cover
S06: 4-M4x10
J3 Motor Unit
