Epson C8-B - Joint #4; Joint #4 Replacing the Timing Belt

C8-B/C12-B Service Manual Maintenance Disclosure Scope: Maintenance Trained Personnel Only
(C) Seiko Epson Corporation 2-132 Rev.1
2.6 Joint #4
2.6.1 Joint #4 Replacing the Timing Belt
J4 Timing Belt
S01: 2-M4x10
J4 Motor Unit
Brake Power Supply
Cable fixing plate
S01: 2-M4x10
Arm4 Side Cover (left)
Arm4 Side Cover (right)
Cable protection plate
S01: 2-M4x10
S02: 2-M4x8
Ground Wire
Arm4 Maintenance Cover
Cable Bracket
S01: 2-M3x6
Cable fixing plate
Arm3 Maintenance Cover
Arm3 Cover
Arm2 Cover
Arm2Cover
Cable fixing plate
