2.3.2 Joint #1 Replacing the Motor Unit
J1 Motor Unit
S06: 6-M4x10
S01: 11-M4x10
S01: 1-M5x15
S01: 3-M4x20
S01: 3-M6x30 and washer
Base Cover
Base Maintenance Cover
J1 Brake
and Brake Plate
Heat Radiation Block
Radiation Sheet
J1 Timing Belt
S01: 8-M4x10
Connector Plate
