C8-B/C12-B Service Manual Maintenance Disclosure Scope: Maintenance Trained Personnel Only
(C) Seiko Epson Corporation 2-300 Rev.1
2.10.3 Replacing the DC/DC Board
DC/DC Board
S06: 6-M4x10
Base Maintenance Cover
S07: 2-M3x6
