Epson C8-B - Joint #2 Replacing the Reduction Gear

C8-B/C12-B Service Manual Maintenance Disclosure Scope: Maintenance Trained Personnel Only
(C) Seiko Epson Corporation 2-63 Rev.1
2.4.4 Joint #2 Replacing the Reduction Gear
C8L: S02: 16-M5x30 and washer
C8XL: S02: 16-M6x35 and washer
Arm2
J2 Pulley 2
S02: 8-M6x25
and washer
S05: 2-M5x10
Wave Generator Unit
J2 Reduction
Gear
Arm1 Side Cover
Arm1 Side Cover
Arm1 Center Cover
S06: 4-M4x10
S06: 4-M4x10
S06: 5-M4x10
O-ring
O-ring
Wave Washer
J2 Timing Belt
C8L: S02: 12-M5x40
C8XL/C12XL: S02: 12-M6x45
