C8-B/C12-B Service Manual Maintenance Disclosure Scope: Maintenance Trained Personnel Only
(C) Seiko Epson Corporation 2-20 Rev.1
Connect the J1 Motor Connectors (CN111, CN311, CN410).
Install the Connector Plate.
M/C Cable Backward: C8L, M/C Cable Backward: C8XL, C12XL
Install the Base Maintenance Cover.
After assembly, perform calibration of Joint #1.
3.2 Calibration
C8L
8
9
10
11
Installing the Motor Unit
10
9
2
7
4
1
2
5
6
