C8-B/C12-B Service Manual Maintenance Disclosure Scope: Maintenance Trained Personnel Only
(C) Seiko Epson Corporation 2-3 Rev.1
Body page for instructions
The configuration of parts
to be removed/attached is
shown by illustrations.
The details of the work, precautions for work, and
points, etc., are described.
CAUTION
Indicates information about risks which may cause
injury to persons and risks which the Manipulator
functions cannot be implemented.
POINT
Indicates a method of proceeding with work in an
efficient manner.
NOTE
Indicates information not concerning the work
procedures.
Work sequence
The white circle numbers (e.g.

) are the step numbers for
removing or disassembling the unit or component.
Black circle numbers (e.g.

) are step numbers for assembling
or installing the unit or component.
Indicates that lubrication is required.
Refer to 1.2.5 Tools/Materials
for grease manufacturer
and other details.
Clicking the underlined blue characters will open the
corresponding page.
You can return to the original page by simultaneously
pressing the [Alt] key and the [] key.
* The operation method may differ depending on the
viewer. For details, refer to Help of each viewer.
