C8-B/C12-B Service Manual Maintenance Disclosure Scope: Maintenance Trained Personnel Only
(C) Seiko Epson Corporation 2-310 Rev.1
Install the fan cover.
POINT
Fix the screws while supporting the fan cover.
2
S04: 4-M4x35 with washer
(0.9 +/- 0.1 N·m)
A
Fan cover
1
2
Installing the Fan
