L1800 Revision A
Disassembly And Assembly Disassembling the Printer Mechanism 60
Confidential
9. Disconnect the two Head FFCs on the back side, and remove the Printhead.
Figure 3-51. Removing the Printhead (2)
Tighten the screws in the order shown in Figure 3-50
A D J U S T M E N T
R E Q U I R E D
After replacing or removing the Printhead, always make the required
adjustments referring to the following.
“Chapter 4 Adjustment (p.109)”
To Next Page
