Epson Stylus Color 1520 Service Manual

EPSON Stylus COLOR 1520
Rev. A
1-
2
Model Description
C82305  /C82306 
Serial interface card
C82307  /C82308 
32 KB serial interface card
C82310 
32 KB parallel interface card
C82313 
32 KB EEE-488 interface card
C82315 
Twinax interface card
C82314 
Coax interface card
C82312 
LocalTalk™ interface card
C82331 
Ethernet interface card
C82345 
Type-B Bidirectional parallel interface card
C83602 
Parallel interface cable (shielded)
from D-SUB 25-pin (computer) to Amphenol 57
(printer)
C83603  /C83604 
Serial interface cable
from D-SUB 25-pin (computer) to D-SUB 25-pin
(printer)
C83605  /C83606 
Serial interface cable
from D-SUB 9-pin (computer) to D-SUB 25-pin
(printer)
C811** 
Banner paper holder and cutting guide
S020108 Black ink cartridge
S020089 Color ink cartridge
S041059 / S041025 EPSON 360 dpi ink jet paper (A4)
S041060 EPSON 360 dpi ink jet paper (Letter)
S041065 EPSON 360 dpi ink jet paper (A3)
S041066 EPSON 360 dpi ink jet paper (Super A3/B)
S041061 / S041026 EPSON photo quality ink jet paper (A4)
S041062 EPSON photo quality ink jet paper (Letter)
S041067 EPSON photo quality ink jet paper (Legal)
S041068 EPSON photo quality ink jet paper (A3)
S041070 EPSON photo quality ink jet paper (B)
S041069 EPSON photo quality ink jet paper (Super A3/B)
S041054 EPSON photo quality ink jet card (A6)
S041121 EPSON photo quality ink jet card (5 X 8 inch)
S041122 EPSON photo quality ink jet card (8 X10 inch)
S041071 EPSON photo quality glossy film (A4)
S041072 EPSON photo quality glossy film (Letter)
S041107 EPSON photo quality glossy film (A6)
S041073 EPSON photo quality glossy film (A3)
S041075 EPSON photo quality glossy film (B)
S041074 EPSON photo quality glossy film (Super A3/B)
S041126 EPSON photo quality glossy paper (A4)
S041124 EPSON photo quality glossy paper (Letter)
S041125 EPSON photo quality glossy paper (A3)
S041123 EPSON photo quality glossy paper (A2)
S041063 EPSON ink jet transparencies (A4)
S041064 EPSON ink jet transparencies (Letter)
S041106 EPSON photo quality self adhesive sheet (A4)
S041103 EPSON 360 dpi ink jet banner paper
S041102 EPSON photo quality banner paper
S041*** EPSON ink jet canvas
S041*** EPSON back light film (A3)
S041*** EPSON back light film (A2)
Note) The asterisk is a substitute for the last digit of the product number,
which varies by country.
Table 1-1. Options and Consumables

Epson Stylus Color 1520 Specifications

General

Color	Yes
Maximum resolution	600 x 1200 DPI
Print speed (black, normal quality, A4/US Letter)	- ppm
Maximum input capacity	100 sheets
Envelopes sizes	10, C5, DL
Standard media sizes	4\
Paper tray media types	Envelopes, Labels, Plain paper
Non-ISO print media sizes	Legal
ISO A-series sizes (A0...A9)	A4
ISO B-series sizes (B0...B9)	B5
Power requirements	120V AC, 50/60 Hz
Printing noise level	45 dB
Maximum operating temperature range (T-T)	-20 - 60 °C
Market positioning	Home & office
