Epson Stylus Color 1520 Service Manual

Disassembly and Assembly
Rev. A
3-1
3
3.2.8 C211 MAIN Board Assembly Removal
1. Remove the upper housing. (Refer to Section 3.2.1.)
2. Remove the printer mechanism unit. (Refer to Section 3.2.6.)
3. Disconnect the connector cable for the PSB/PSE board from CN2, and the Control Panel FFC from
CN7.
4. Remove 7 screws (CBP, 3X12) and 2 screws (CBS, M3X6) securing the C211 MAIN board assembly
to the lower housing. Then remove the C211 MAIN board assembly, along with the Type-B interface
shield cover.
5. Remove 2 screws (CP, M3X6) securing the Type-B interface shield cover to the C211 MAIN board.
Then remove the shield cover.

When the C211 MAIN board is replaced, be sure to reset the EEPROM prior to adjustments to
avoid a failure such as bugged data.
 Be careful when servicing the lithium Battery. (Refer to Section 3.1.1.)
 Pay attention to the sharp edges of the shield cover.
REQUIRED ADJUSTMENT
WARNING

Epson Stylus Color 1520 Specifications

General

Color	Yes
Maximum resolution	600 x 1200 DPI
Print speed (black, normal quality, A4/US Letter)	- ppm
Maximum input capacity	100 sheets
Envelopes sizes	10, C5, DL
Standard media sizes	4\
Paper tray media types	Envelopes, Labels, Plain paper
Non-ISO print media sizes	Legal
ISO A-series sizes (A0...A9)	A4
ISO B-series sizes (B0...B9)	B5
Power requirements	120V AC, 50/60 Hz
Printing noise level	45 dB
Maximum operating temperature range (T-T)	-20 - 60 °C
Market positioning	Home & office
