Product Description
Rev. A
1-2
1.4.6 Printer Adjustment Mode
The EPSON Stylus COLOR 1520 allows users to adjust the printing direction and head gap without a
special program. The following chart shows the adjustments method .
1.4.6.1 Adjustment Method
1.4.6.2 Adjustment patterns
Pattern Menu
Pattern 1 Uni-dir adjustment at 400 cps (with an increment of 1/1,440 inch)
Pattern 2 Bi-dir adjustment at 400cps (with an increment of 1/1,440 inch)
Pattern 3 Bi-dir adjustment at 200cps (with an increment of 1/1,440 inch)
Pattern 4 Head gap adjustment between black and color to the cross feed
direction at 200 cps (with an increment of 1/720 inch)
Pattern 5 Head gap adjustment between black and color to the cross feed
direction at 100 cps (with an increment of 1/720 inch)
Adjust a patterns ?
NO
YES
NO
Start
YES
Turn the printer off once to save the new settings into the EEPROM.
More adjustment ?
Press the Load/Eject button.
1.Move through the languages listed
by pressing the alt button.
2.Select the language by pressing
the Pause button.
The printer prints the instruction
sheet on how to adjust the printer.
Press the Pause button,
The printer prints the instruction
sheet on how to select the language.
and
turn
on the printer.
1. Select the appropriate test by
pressing the Alt button.
2. Press the Load/Eject button.
The printer prints the test patterns.
Select the most closely aligned pattern
by pressing the Pause button.
Figure 1-12. Printer Adjustment Flow Chart
Table 1-29. Printer Adjustment Patterns
To Next Page
