Product Description
Rev. A
1-3
3
1.6.2 C172 PSB/PSE Board
This board consists of a transformer, switching FET, regulator IC, diode bridge, fuse, and so on.
Fuse
Regulator IC
Transformer
Diode Bridge
Switching FET
Figure 1-14. C211 PSB/PSE Board Component Layout
