Epson Stylus Color 1520 Service Manual

EPSON Stylus COLOR 1520
Rev. A
1-
6
1.2.5 Paper Specification
1.2.5.1 Cut Sheet
Size Width Length
A4 210 mm (8.3”) 297 mm (11.7”)
Letter 215.9 mm (8.5”) 279.4 mm (11.0”)
B5 182 mm (7.2”) 257 mm (10.1”)
Legal 215.4 mm (8.5”) 355.6 mm (14.3”)
B4 257 mm (10.1”) 364 mm (14.0”)
A3 297 mm (11.7”) 420 mm (16.5”)
Ledger 279.4mm (11.0”) 431.8 mm (17.0”)
A3 wide 329 mm (13.0”) 483 mm (19.0”)
A2 420 mm (16.5”) 594 mm (23.4”)
US-C 431.8 mm (17.0”) 558.8 mm (22.0”)
B5 (ISO) 176 mm (6.9”) 250 mm (9.8”)
B4 (ISO) 250 mm (9.8”) 353 mm (13.9)”
 Paper Thickness :0.065 mm (0.0025”) to 0.11 mm (0.004”)
 Paper Weight :64 g/ m
2
(17 lb.) to 90 g/ m
2
(24 lb.) (ASF)
:52 g/ m
2
(14 lb.) to 90 g/ m
2
(24 lb.) (Manual insertion)
 Quality :Exclusive paper *
2
, Bond paper, PPC
Note) 1. A2 portrait and US-C portrait are used by manual insertion only.
2. Be sure to use the designated side of exclusive paper.
1.2.5.2 Transparency
Size Width Length
A4 210 mm (8.3”) 297 mm (11.7”)
Letter 215.9 mm (8.5”) 279.4 mm (11.0”)
 Paper thickness :0.075 mm (0.003”) to 0.085 mm (0.0033”)
Note) Transparency printing is only available at normal temperatures.
Transparency paper must be printed on the designated side.
1.2.5.3 Envelope
Size Width Length
No.10 241.3 mm (9 1/2”) 104.8 mm (4 1/8”)
DL 220 mm (8.7”) 110 mm (4.3)
C5 229 mm (9”) 162 mm (6.4)
 Paper Thickness :0.16 mm (0.006”) to 0.52 mm (0.02”)
 Paper Weight :45 g/m
2
(12 lb.) to 90 g/ m
2
(24 lb.)
 Quality :Bond paper, Plain paper, Air mail
Note) Envelope printing is only available at normal temperatures.
Place the longer side of the envelope horizontally when setting.
1.2.5.4 Index Card
Size Width Length
A6 index card 105 mm (4.1”) 148 mm (5.82”)
 Card Thickness :0.23 mm (0.0091”)
Table 1-5. Cut Sheet Size
Table 1-6. Transparency Size
Table 1-7. Envelope Size
Table 1-8. Index Card Size

Epson Stylus Color 1520 Specifications

General

Color	Yes
Maximum resolution	600 x 1200 DPI
Print speed (black, normal quality, A4/US Letter)	- ppm
Maximum input capacity	100 sheets
Envelopes sizes	10, C5, DL
Standard media sizes	4\
Paper tray media types	Envelopes, Labels, Plain paper
Non-ISO print media sizes	Legal
ISO A-series sizes (A0...A9)	A4
ISO B-series sizes (B0...B9)	B5
Power requirements	120V AC, 50/60 Hz
Printing noise level	45 dB
Maximum operating temperature range (T-T)	-20 - 60 °C
Market positioning	Home & office
