Epson Stylus Color 1520 Service Manual

EPSON Stylus COLOR 1520
Rev. A
1-3
0
1.4.7 Printer Initialization
This printer has three initialization types: Power-on initialization, Operator initialization, and Software
initialization.
 Power-on Initialization
This printer is initialized when turning on the printer. Then the printer recognizes the cold reset command
(Remote RS command). When the printer is initialized, following actions are performed:
 Initialize the printer mechanism.
 Clears input data buffer.
 Clears download character set.
 Clears print buffer.
 Sets default values.
 Operator Initialization
This printer is initialized when Pause button is pressed for 3 seconds, or the printer recognizes the /INIT
signal (negative pulse) of parallel interface. When the printer is initialized, following actions are
performed:
 Clears input data buffer.
 Clears download character set.
 Clears print buffer.
 Sets default values.
 Software Initialization
This initialization is performed by the ESC @ commend and the following actions are performed:
 Clears print buffer.
 Sets default values.
1.4.8 Self-test Printing Mode
This printer has the self-test printing mode. Following items are checked by performing this mode.
 Function for the control circuit board
 Function for the printer mechanism
 Print quality
The printer enters the LQ self-test printing mode by pressing the Load/eject button while turning on the
printer. To enter the draft self-test printing mode by pressing the LF/FF button while turning on the
printer.
1.4.9 Hexadecimal Dump Function
Pressing the LF/FF and Load/Eject buttons while turning on the printer activates the hexadecimal dump
mode. Each line has Hexadecimal codes, along with their corresponding letters printed in the right
column. If a received code denotes an unprintable character. Such as a control code, “.” (period) is
printed in the right column. This function enables users to check whether the data from the host is
properly transferred. Turn off the printer to exit the mode.
1.4.10 Monochrome Printing Mode
When the printer is in the ink end (color) condition, the black ink is substituted to continue to work. In
order to switch to monochrome printing mode, turn the printer off and back on. This mode is also
selected by the command “
ESC (K)
“. The Color select command “
ESC r
” is ignored in this mode.

Epson Stylus Color 1520 Specifications

General

Color	Yes
Maximum resolution	600 x 1200 DPI
Print speed (black, normal quality, A4/US Letter)	- ppm
Maximum input capacity	100 sheets
Envelopes sizes	10, C5, DL
Standard media sizes	4\
Paper tray media types	Envelopes, Labels, Plain paper
Non-ISO print media sizes	Legal
ISO A-series sizes (A0...A9)	A4
ISO B-series sizes (B0...B9)	B5
Power requirements	120V AC, 50/60 Hz
Printing noise level	45 dB
Maximum operating temperature range (T-T)	-20 - 60 °C
Market positioning	Home & office
