EPSON Stylus
COLOR
1520
Rev. A
4-
4.1.2 Initialize Operation
This operation is performed to write the factory values in the EEPROM on the MAIN board. With this
operation, the factory values are written in at a time.
1. Connect the printer and the host computer with a parallel interface cable.
2. Start the adjustment program in the host computer.
3. Select “CUSTOMER SET” in the 1
st menu and press the Enter key.
4. Move the cursor using
or
key to select an appropriate customer code and area. Then press the
Enter key, and the main menu appears on the monitor.
5. Move the cursor using
or
key to select “ADJUST” in the 1st menu. Then press the Enter key, and
the main menu appears on the monitor.
6. Move the cursor using
or
key to select “INITIALIZE”. Then press the Enter key to execute the
initialization. Then press the Enter key to return to the main menu.
7. Select other adjustment using
or
key, or select RETURN TO 1st MENU to exit the main menu.
8. Move the cursor using
or
key to select “END” and press the Enter key to exit the program.
Note
1. Unless
“CUSTOMER SET”
is executed, the program does not proceed to the main menu.
2. Input of an incorrect customer code does not assure the proper operation of the program.
WORK POINT
Adjusted values are not stored in the EEPROM until the printer is turned off. Therefore be sure to
turn off the printer once after the adjustment program is executed.
The set value is transferred to the printer when this operation is executed. Therefore do not turn
off the printer before executing “
INITIALIZE”
.
To Next Page
