Epson Stylus Color 1520 Service Manual

EPSON Stylus COLOR 1520
Rev. A
3-
8
3.2.3.2 Color Head Removal
1. Remove the upper housing. (Refer to Section 3.2.1.)
2. Remove the ink cartridge if it is installed.
3. Remove the FFC holders from the front left corner of the CR unit. Then release the FFCs by pulling
them toward the printhead side.
4. Disconnect the color FFC from the color head connector.
5. Remove the Cartridge Lever.
6. Remove the compression spring fixing the black head to the CR unit.
7. Remove the screw securing the color head to the CR unit.
8. Shift the color head forward then remove it by lifting upward.

When removing the black head, be careful not to catch the color head FFC.
 Be careful not to damage the Head FFCs when pulling them from the corner of the CR unit.
 After replacing the head, perform the following:
(Refer to Chapter 4, Adjustment.)
 Head data writing
 Head angle adjustment
 Head vertical adjustment
 Head gap adjustment
WORK POINT
REQUIRED ADJUSTMENT

Epson Stylus Color 1520 Specifications

General

Color	Yes
Maximum resolution	600 x 1200 DPI
Print speed (black, normal quality, A4/US Letter)	- ppm
Maximum input capacity	100 sheets
Envelopes sizes	10, C5, DL
Standard media sizes	4\
Paper tray media types	Envelopes, Labels, Plain paper
Non-ISO print media sizes	Legal
ISO A-series sizes (A0...A9)	A4
ISO B-series sizes (B0...B9)	B5
Power requirements	120V AC, 50/60 Hz
Printing noise level	45 dB
Maximum operating temperature range (T-T)	-20 - 60 °C
Market positioning	Home & office
