1.2.5.5 Labels (Cut Sheet)
Size Width Length
A4 210 mm (8.3”) 297 mm (11.7”)
Letter 216 mm(8.5”) 279 mm (11.0”)
 Paper thickness :0.2 mm (0.0079”) including base sheet
 Quality :Page printer label
Note) Label must be printed at normal room temperature.
1.2.5.6 Continuous Paper
 Paper size :Paper width 101.6 mm (4”) to 406.4 mm (16”)
:Folding length 101.6 mm (4”)
 Paper thickness :0.065 mm (0.0026”) to 0.11 mm (0.0043”)
 Paper Weight :52 g/ m
2
(14 lb.) to 82 g/ m
2
(22 lb.)
1.2.5.7 Labels (Continuous)
 Paper size
 Base sheet :Paper width 101.6 mm (4”) to 406.4 mm (16”)
:Folding length 101.6 mm (4”)
 Label :Width 63.5 mm (2.5”)
:Length 23.9 mm (0.94”)
 Paper thickness :0.2 mm (0.0079”) or less including base sheet
:0.12 mm (0.0047”) or less without base sheet
 Quality :Plain paper
Note) Label (continuous) must be printed under normal room temperatures.
1.2.5.8 Banner
 Size :Width :210 mm (8.32) to 432 mm (17.0”)
:Length :5.0 m or less (196.9”)
 Thickness :0.08 mm (0.0031”) to 0.1 mm (0.0039”)
 Weight :64 g/m
2
(17 lb.) to 82 g/ m
2
(22 lb.)
 Quality :Plain paper
Table 1-9. Label Size

Epson Stylus Color 1520 Specifications

General

Color	Yes
Maximum resolution	600 x 1200 DPI
Print speed (black, normal quality, A4/US Letter)	- ppm
Maximum input capacity	100 sheets
Envelopes sizes	10, C5, DL
Standard media sizes	4\
Paper tray media types	Envelopes, Labels, Plain paper
Non-ISO print media sizes	Legal
ISO A-series sizes (A0...A9)	A4
ISO B-series sizes (B0...B9)	B5
Power requirements	120V AC, 50/60 Hz
Printing noise level	45 dB
Maximum operating temperature range (T-T)	-20 - 60 °C
Market positioning	Home & office
