Epson Stylus Color 1520 Service Manual

Product Description
Rev. A
1-1
9
1.3.3 Optional Interface
The EPSON Stylus COLOR 1520 supports an optional Type-B interface (Level 2) with the following
characteristics.
 Reply message
 When ESC/P2 is selected:
Main type :MTP48p, PW136cl10cpi, PRG(W0xxxx)rev, AP800ma, SPD0fast
Product name :Stylus COLOR 1520
Emulation type :ESCPL2-00
Entity type :EPSONLQ2
 When X24E is selected:
Main type :MTP48p, PW136cl10cpi, PRG(W0xxxx)rev, AP800ma, SPD0fast
Product name :Stylus COLOR 1520
Emulation type :PRPXL24-00
Entity type :EPSONPRPXL24
Option command No. command name Reply-A Reply-B
00h No Operation Accept None
01h Start Hard Ware Reset Accept Excute OK
02h Start Soft Ware Reset Reject
03h Send Main System Type Accept
04h Send Name Data Reject
05h Inquire Name Data Accept
06h Send Product Name Accept
07h Send Soft Ware Emulation Type Accept
08h Complete Buffered Data Accept Check Condition
09h Stop Procedure Reject Execute OK
0Ah Return Buffered Data Reject
0Bh Send Entity Type Accept
0Ch Send Status Accept
0Dh Quit Procedure Reject
0Eh Inquire ASCII Message Reject
0Fh Send ASCII Message Accept None
10h - 13h Unknown None
14h Inquire Emergency Message Accept Execute OK
15h Send Emergency message Accept
16h - 1Fh Unknown None
20h - FFh Reserved None
Main Command No. Command name Sending Timing
01h Start Software Reset  /INIT signal on the std. parallel I/F
 Type-B I/F option command : 01h
 Cold Start
04h Send Name Data  Type-B I/F command : 05h
07h Inquire Software Emulation Name  Changing software Emulation Type
0Eh Inquire ASCII Message  Writing to DBIN register
14h Inquire Emergency Reply  Reply for Emergency command
15h Send Emergency Message  Receive Emergency Command
 Emergency Command
0X00 :Get device ID
0X01 :Get all status
 Sending BDC-ST through DBIN register
When State-Reply is set “ON”, by ST from Type-B I/F, sending BDC-ST through DBIN register is
started. When State-Reply is started, “Start” and “End” of BDC-ST characters are announced by
sending the Main command 0Eh.
Table 1-21.Reply for Option Command
Table 1-22. Supported Main Command and Sending Timing

Epson Stylus Color 1520 Specifications

General

Color	Yes
Maximum resolution	600 x 1200 DPI
Print speed (black, normal quality, A4/US Letter)	- ppm
Maximum input capacity	100 sheets
Envelopes sizes	10, C5, DL
Standard media sizes	4\
Paper tray media types	Envelopes, Labels, Plain paper
Non-ISO print media sizes	Legal
ISO A-series sizes (A0...A9)	A4
ISO B-series sizes (B0...B9)	B5
Power requirements	120V AC, 50/60 Hz
Printing noise level	45 dB
Maximum operating temperature range (T-T)	-20 - 60 °C
Market positioning	Home & office
