Epson Stylus Color 1520 Service Manual

Product Description
Rev. A
1-2
3
1.4.2 Panel Functions at Power On
This printer also enters various functions by turning on the printer while holding down a button
( buttons). Each combination and corresponding function is described in the table below.
Switch *
1
(while turning on the printer)
Function
Micro adjust 

Enters default setting mode. (See Section 1.4.4.)
Pause Enters printer adjustment mode. (See Section 1.4.5.)
Load /Eject Enters LQ self-test printing mode.
LF/FF Enters draft self-test printing mode.
LF/FF + Load/Eject Enters hex-dump mode.
Alt + LF/FF + Load/Eject
+ Micro adjust 

Enters EEPROM and Timer IC reset *
2
mode.
Note) 1.”+” means to press one button while holding down the other button(s).
2.EEPROM and Timer IC must be reset only by qualified service personnel.
When performing EEPROM reset operation, waste ink drain pads must be replaced. Therefore
EEPROM reset is to be performed by a qualified service person only. (See Chapter 3.)
Table 1-23. Panel Functions at Powered On
CAUTION

Epson Stylus Color 1520 Specifications

General

Color	Yes
Maximum resolution	600 x 1200 DPI
Print speed (black, normal quality, A4/US Letter)	- ppm
Maximum input capacity	100 sheets
Envelopes sizes	10, C5, DL
Standard media sizes	4\
Paper tray media types	Envelopes, Labels, Plain paper
Non-ISO print media sizes	Legal
ISO A-series sizes (A0...A9)	A4
ISO B-series sizes (B0...B9)	B5
Power requirements	120V AC, 50/60 Hz
Printing noise level	45 dB
Maximum operating temperature range (T-T)	-20 - 60 °C
Market positioning	Home & office
