Epson Stylus Color 1520 Service Manual

EPSON Stylus COLOR 1520
Rev. A
3-1
4
CN3
CN4
Screw (CBS 3x12)
Screw (CBP 3X12)
Screw (CBS 3X6)
CN14
CN12
CN13
CN5
CN15
Connector Cable
for ther Control Panel
Screw (CBP 3X12)
Screw (CBP 3X12)
Screw (CBS 3X6)
Screw (CP 3X6)
Shield Cover for the
Type-B I/F
CN8
CN11
FFCs for the Heads
CN10
CN9
Screws (CBS 3x12)
CN2
Lower Housing
Main Board Assembly
Figure 3-10. C202 MAIN Board Removal

Epson Stylus Color 1520 Specifications

General

Color	Yes
Maximum resolution	600 x 1200 DPI
Print speed (black, normal quality, A4/US Letter)	- ppm
Maximum input capacity	100 sheets
Envelopes sizes	10, C5, DL
Standard media sizes	4\
Paper tray media types	Envelopes, Labels, Plain paper
Non-ISO print media sizes	Legal
ISO A-series sizes (A0...A9)	A4
ISO B-series sizes (B0...B9)	B5
Power requirements	120V AC, 50/60 Hz
Printing noise level	45 dB
Maximum operating temperature range (T-T)	-20 - 60 °C
Market positioning	Home & office
