Epson Stylus Color 1520 Service Manual

EPSON Stylus COLOR 1520
Rev. A
A-22
Reference No. Description Part Price List Name
636 Right Slide Cover 1026106
637 Left Slide Cover 1026107
640 Paper Load Shaft 1026062
641 Guide Edge Shaft 1026068
642 ASF Release Shaft 1026069
643 Platen Shaft Holder F334005230
644 Platen Shaft holder F334005370
648 Wire Saddle 1003192
649 Bushing 6 1019437
650 Gear 16 1031864
652 Gear 11.4 1025967
653 Combination Gear 13.8, 11 1025968
654 Gear 17 1025969
655 Gear 12 1025970
656 Combination Gear 22, 8.4 1026049
657 Gear 8 1026050
658 Combination Gear 48, 45 1026051
659 Gear 33.6 1033679
660 Gear 24 1026055
661 Gear 29 1026081
662 LD Gear 1026083
663 Gear 14.5 1031865
664 Gear 40 1026111
665 Gear 46 1026112
666 Compression Spring 1.96 1026119
667 Gear 16.5 1026254
668 Compression Spring 450 1020350
669 Compression Spring 0.39 1032065
670 Extension Spring 23.2 1026003
671 Compression Spring 0.65 1034197
672 Extension Spring 7.63 1026040
673 Compression Spring 1.13 1026072
674 Compression Spring 2.16 1027830
675 Extension Spring 0.698 1027885
677 Plain Washer B100154712
678 Plain Washer B100166012
679 Plain Washer B100167090
681 Plain Washer 6.1X0.3X12, L/NA 1020296
682 Plain Washer 4.2X0.3X8, L/N 1006142
683 Plain Washer, 3X0.5X8 F/ZN 1008492
684 Plain Washer 5.32X0.6X17.6 F/ZN 10030008
685 Leaf Spring B101253990
686 Spring Pin B130103216
687 Ball Bearing B210151690
688 Hexagon Nut B070200311
689 Flange Nut B081700611
690 Plain Washer B100153090
696 Retaining Ring B150300611
697 Retaining Ring B150300711
698 Retaining Ring B150300811
699 Retaining Ring B150300911
700 Retaining Ring B1050350111
701 Cup Screw B041450311
702 Screw (CBS) B300204211
704 Screw (CBP, 3x8) 1005019
Table A-17. Part No. Reference Table (4)

Epson Stylus Color 1520 Specifications

General

Color	Yes
Maximum resolution	600 x 1200 DPI
Print speed (black, normal quality, A4/US Letter)	- ppm
Maximum input capacity	100 sheets
Envelopes sizes	10, C5, DL
Standard media sizes	4\
Paper tray media types	Envelopes, Labels, Plain paper
Non-ISO print media sizes	Legal
ISO A-series sizes (A0...A9)	A4
ISO B-series sizes (B0...B9)	B5
Power requirements	120V AC, 50/60 Hz
Printing noise level	45 dB
Maximum operating temperature range (T-T)	-20 - 60 °C
Market positioning	Home & office
