EPSON Stylus COLOR 440, 640, and 740 Chapter 4 Disassembly and Assembly
97
Figure 4-7. Installing the Printhead
C a rria g e A s s e m b ly
These pins should fit
through the holes on the
grounding plate.
This part of the grounding plate
should touch the C R
guide shaft bushing.
M a k e s u re th a t th is
p in fits in to th e n o tc h
on the printhead.
N ozzle S elector (440): 1 piece
N ozzle S elector (640): 2 pieces
Stylus C olor 740
CARRIAGE
(T O P
VIEW )
PRINTHEAD
(R E A R
VIEW )
Stylus C olor 440 and 640
N o z z le S e le c to r IC n o t v is ib le
