EPSON Stylus COLOR 440, 640, and 740 Chapter 1 Product Description
12
Envelopes
Table 1-6 and Fi
g
ure 1-5 show the printable area for envelopes.
Table 1-6. Printable Area for Envelopes
Figure 1-5. Printable Area for Envelopes
1.2.3.1 Adjust Lever Setting (PG Adjust Lever)
The ad
j
ust lever
(
blue
)
on the ri
g
ht side under the printer cover needs to
be set to the proper position for the paper
y
ou print on.
(
See Table 1-7.
)
If
y
ou find that the paper wrinkles durin
g
printin
g
, or if smud
g
es appear
on the paper, move the lever to the + position
(
toward the rear
)
,
re
g
ardless of paper t
y
pe.
Table 1-7. Adjust Lever Setting
NOTE: Always return the adjust lever to the zero position after you
finish printing. Leaving the lever in the plus position may cause
poor printing in the next printout.
Envelope
Size
LM (Minimum
Left Margin)
RM (Minimum
Right Margin)
TM (Minimum
Top Margin)
BM (Minimum
Bottom Margin)
#10 0.12” (3 mm) 1.10” (28 mm) 0.12” (3 mm)
0.54” (14 mm)
0.12” (3 mm)
DL 0.12” (3 mm) 0.28” (7 mm) 0.12” (3 mm)
0.54” (14 mm)
0.12” (3 mm)
C6 0.12” (3 mm) 0.12” (3 mm) 0.12” (3 mm)
0.54” (14 mm)
0.12” (3 mm)
RM
TM
LM
Printable
Area
BM
Lever Position Clearance between head and platen
Plus position 1.04 mm
Zero position 1.74 mm (+0.7 mm)
