EPSON Stylus COLOR 440, 640, and 740 Chapter 1 Product Description
31
1.8.2 C206 MAIN-B Board (Stylus COLOR 440)
The C206 MAIN-B board controls the operation of the printer
mechanism and data processin
g
operations for the St
y
lus COLOR 440.
This board will eventuall
y
be replaced b
y
the C255 MAIN board.
The C206 MAIN-B board consists of the followin
g
ma
j
or components:
Figure 1-12. C206 MAIN-B board
1.8.3 C256 MAIN Board (Stylus COLOR 640)
The C256 MAIN board controls the operation of the printer mechanism
and data processin
g
operations for the St
y
lus COLOR 640. It consists
of the followin
g
ma
j
or components.
Figure 1-13. C256 MAIN board
CN1
B a tt 1
IC 7(H ead)
CN6CN7
IC 4 (4 M D -R A M )
IC 1 (C P U )
IC 14(PF)IC 15(C R )
IC 3 (P -R O M )
IC 2 (A s ic )
CN10
Q 7,Q 9(H ead)
CN8
EEPRO M
(IC 1 1 )
CN3
CN5
CN4
CN11
IC 14(PF)
IC 2 (A s ic )
CN1
CN2
B a tt 1
IC 15(C R )
CN10
IC 7(H ead)
Q 7,Q 9(H ead)
CN8
CN6CN7
CN3
CN5
CN4
CN11
IC 16(P-R O M )
IC 6
IC 5 (4 M D -R A M )
IC 1 (C P U )
