EPSON Stylus COLOR 440, 640, and 740 Chapter 5 Adjustments
118
5.2 Adjustments
The sections below provide specific instructions for each t
y
pe of
ad
j
ustment.
5.2.1 Parallelism Adjustment
You must perform the parallelism ad
j
ustment after replacin
g
or
removin
g
the carria
g
e
g
uide shaft, or if
y
ou chan
g
e the settin
g
of the
parallelism ad
j
ustment bushin
g
s. This ad
j
ustment sets the standard
distance from the printhead to the paper surface.
1.
Set the ri
g
ht and left parallelism ad
j
ustment bushin
g
s to the center
position mark. This is where the rid
g
e on the top of each bushin
g
ali
g
ns with the notch and the screw hole on the metal frame. See
Fi
g
ure 5-2.
Right Parallelism Adjustment
2.
Set the PG lever to 0
(
forward
)
. This minimizes the
g
ap between
the printhead and the platen.
3.
Move the carria
g
e to the center of the platen. Then set the
thickness
g
au
g
e on the ri
g
ht side of the platen as shown in Fi
g
ure
5-1 on the next pa
g
e.
4.
Move the carria
g
e so it’s over the thickness
g
au
g
e.
5.
Move the ri
g
ht parallelism ad
j
ustment bushin
g
to the rear, which
narrows the
g
ap, until the thickness
g
au
g
e moves with the carria
g
e
when
y
ou slide the carria
g
e about 1 inch
(
20 mm
)
in either direction.
6.
Move the ad
j
ustment bushin
g
one notch forward to widen the
g
ap.
7.
Set the PG lever to 0
(
small
g
ap
)
and slide the carria
g
e ri
g
ht and left
to make sure that the thickness
g
au
g
e doesn’t move with the
carria
g
e.
Left Parallelism Adjustment
8.
Perform steps 2 throu
g
h 7 to ad
j
ust the left parallelism ad
j
ustment
bushin
g
. But this time set the thickness
g
au
g
e on the left side of the
platen
(
see Fi
g
ure 5-1
)
.
Checking parallelism
9.
Perform steps 2 throu
g
h 4 a
g
ain, with the thickness
g
au
g
e set on
the ri
g
ht side of the platen.
10.
Make sure that the thickness
g
au
g
e does not move alon
g
with the
carria
g
e when the carria
g
e is moved about 1 inch
(
20 mm
)
in either
direction.
11.
Move the ri
g
ht parallelism ad
j
ustment bushin
g
one notch to the rear
(
the
g
ap will be narrowed
)
. Then check that the thickness
g
au
g
e
moves alon
g
with the carria
g
e. If the thickness
g
au
g
e does not
move,
g
o back to step 2 and repeat the ad
j
ustment.
CAUTION
Do not scratch the ribbed surface of the platen or the
special coating on the PF roller.
To avoid damaging the printhead, never use a rusty,
dirty, or bent thickness gauge. Clean the gauge
before using it, and avoid pressing it hard against the
head.
CAUTION
Put the thickness gauge on the flat part of the
platen ribs, as shown in
Fi
g
ure 5-1
.
Move the carriage by pulling it with the timing
belt.
