EPSON Stylus COLOR 440, 640, and 740 Chapter 1 Product Description
33
1.8.6 C206 PNL Board (Stylus COLOR 440 and 640)
The C206 PNL
(
panel
)
board is located in the panel housin
g
on the front
of the printer. It consists of 3 buttons, 4 LEDs, and 1 connector.
Figure 1-16. C206 PNL board
1.8.7 C209 PNL Board (Stylus COLOR 740)
The C209 PNL
(
panel
)
board is located in the panel housin
g
on the front
of the printer. It consists of 3 buttons, 4 LEDs, and 1 connector.
Figure 1-17. C209 PNL Board
SW0
SW2
SW1
LED4
LED0
LED1
LED2
CN1
SW0
SW2
SW1
LED4
LED0
LED1
LED2
