Epson Stylus Color 740 Service Manual

EPSON Stylus COLOR 440, 640, and 740 Appendix
159
A.4
EEPROM Address Map (Stylus COLOR 740)
Table A-26 lists the EEPROM addresses for the St
y
lus COLOR 740.
.
CAUTION
The address information contained in this section
applies only to the Stylus COLOR 740. If you need
information on the Stylus COLOR 440 or 640, refer to
Section A.3
.
Table A-26. Stylus COLOR 740 EEPROM Address Map
Address Explanation Setting
QPIT
Settings
Factory
Settings
00H Password 0 0FH —
01H 5AH —
02H EEPROM
mapping revision
41H —
03H Board lD 0: On-board RAM is 8 Mbit.
1: On-board RAM is 16 Mbit.
00H (*1)
04H CG 0: STD, 1: NLSP 00H (*1)
05H Market lD 0: Standard (World)
2: Custom
00H (*1)
06H Custom EEPROM
sub number
00H 00H
07H 00H 00H
08H 00H 00H
09H 00H 00H
0AH Head actuator
rank lD for VhN
00H (*1)
0BH Head actuator
rank ID for Vh
µ
00H (*1)
0CH Head actuator
rank ID for VhL
00H (*1)
0DH Head actuator
rank lD for AR
00H (*1)
0EH Head rank MW-ID 00H (*1)
0FH Reserved for
Head lD
00H —
10H Reserved for
Head lD
00H —
11H Reserved for
Head ID
00H —
12H Head actuator
rank lD for lwAB
00H (*1)
13H Head actuator
rank lD for lwCD
00H (*1)
