EPSON Stylus COLOR 440, 640, and 740 Appendix
158
Notes:
**: Change the model name of the IEEE-1284 Device ID.
*1. Set at the factory.
*2. Set when the EEPROM is intialized from the control panel.
*3. 01H is a factory setting for the Pacific market. (At address 35H, this note applies
only to the Stylus COLOR 440.)
*4. This address sets the dot size when the user selects “Economy Mode” (180 x 180
dpi) from the printer driver. Ink life is increased by choosing Normal
×
1 dot (01H),
but the output will be paler than when using the factory-set Normal
×
2 dot (00H).
Stylus Color 440/640 EEPROM Address Map (Continued)
Address Explanation Setting
QPIT
Settings
Factory
Settings
48H Ink counter
CY (total)
1 count=100 ng
00H 00H
49H 00H 00H
4AH 00H 00H
4BH 00H 00H
4CH Ink counter Cm
(total)
1 count=100 ng
00H 00H
4DH 00H 00H
4EH 00H 00H
4FH 00H 00H
50H Password 5 5AH -
51H 0FH -
52H Ink counter
Cc (total)
1 count=100 ng
00H 00H
53H 00H 00H
54H 00H 00H
55H 00H 00H
56H Ink counter Csm
(total)
1 count=100(ng)
00H 00H
57H 00H 00H
58H 00H 00H
59H 00H 00H
5AH Ink counter
Custodial
1 count=100 ng
00H 00H
5BH 00H 00H
5CH 00H 00H
5DH 00H 00H
5EH Reserved 00H -
5FH Reserved 00H -
60H Password 6 5AH -
61H 0FH -
62H Ink counter Rb 00H 00H
63H 00H 00H
64H Ink counter Ry 00H 00H
65H 00H 00H
Stylus Color 440/640 EEPROM Address Map (Continued)
Address Explanation Setting
QPIT
Settings
Factory
Settings
66H Ink counter A 00H 00H (
∗
2)
67H 00H 00H (
∗
2)
68H Power off time 00H 00H (
∗
2)
69H 00H 00H (
∗
2)
6AH CL time 00H 00H (
∗
2)
6BH 00H 00H (
∗
2)
6CH Accumulated
printing time
0: 0 minute
1: 15 minutes
2: 30 minutes
3: 60 minutes
4: 90 minutes
5: 120 minutes
00H 00H
6DH 00H 00H
6EH
Stylus COLOR 440
Dot size for
Economy mode
0: Normal
×
2 dot
1: Normal
×
1 dot
00H 00H
(*4)
Stylus COLOR 640
Reserved
00H -
6FH Reserved 00H -
70H Password 7 5AH -
71H 0FH -
72H to
79H,
7AH to
7FH
Customized
model name
string of counter
strings of model field for
Device ID
00H 00H
To Next Page
