Epson Stylus Color 740 Service Manual

EPSON Stylus COLOR 440, 640, and 740 Chapter 4 Disassembly and Assembly
100
Figure 4-9. Removing the Pump and Capping Assemblies
R em ove these tw o screw s to
loosen the plate on the front.
R elease these hooks from
the fram e, then lift the capping
m echanism to free the hooks
at the other end. D rop the
w hole assem bly out the bottom .
Pump Mechanism
C apping M echanism
R elease the hook securing the
pum p m echanism to the fram e,
and rem ove the pum p.
1
2
R e m o v e th e tw o N o .5 s c re w s
securing the pum p to the
fram e.
3
4
