EPSON Stylus COLOR 440, 640, and 740 Chapter 4 Disassembly and Assembly
110
Figure 4-19. Removing the Carriage Assembly
PG Support Lever
Right Parallelism Adjustm ent Bushin
g
Washer
(C onvex side should face inw ard tow ard the bushing.)
Left P arallelism
A
djustm ent B ushing
C R G uide S haft
C arriage A ssem bly
