EPSON Stylus COLOR 440, 640, and 740 Appendix
154
Table A-24. Printhead Connector (CN9)
Pin Signal Name I/O Function
1 BCO In Black ink cartridge detect signal
2 CCO In Color ink cartridge detect signal
3 THM In Thermistor detect signal
4 GND Ground
5 LAT Out Head data latch pulse output
6 GND Ground
7 SI6 Out Head data output (6)
8 SI5 Out Head data output (5)
9 SI4 Out Head data output (4)
10 SI3 Out Head data output (3)
11 SI2 Out Head data output (2)
12 SI1 Out Head data output (1)
13 GND Ground
14 CLK Out Clock pulse for head data transfer
15 GND Ground
16 NCHG Out Head all on pulse output
17 GND Ground
18 VDD Logic power supply (+5 V)
19 GND2 Ground
20 GND2 Ground
21 GND2 Ground
22 GND2 Ground
23 COM Head drive power supply
24 COM Head drive power supply
25 COM Head drive power supply
26 COM Head drive power supply
27 VHV Head drive voltage control signal
