Epson Stylus CX4900 - 4.3 Disassembly Procedures

EPSON Stylus CX4900/CX4905/CX5000/DX5000/DX5050/CX5900/CX6000/DX6000/DX6050 Revision A
DISASSEMBLY/ASSEMBLY Disassembly Procedures 127
4.3 Disassembly Procedures
The flowchart below shows step-by-step disassembly procedures. When disassembling each unit, refer to the page number shown in the figure.
Figure 4-1. Disassembling Flowchart
START
“4.4.6 Housing, Upper” (p132)
“4.4.9 Printer Mechanism/Housing, Lower”
(p136)
“4.4.12 Main Board Unit/Card Slot Unit”
(p143)
“4.4.20 Carriage Unit/CR Encoder Board/PW
Sensor Board/Head FFC” (p154)
“4.4.25 Paper Guide Front Unit” (p162)
“4.4.26 PG Sensor” (p163)
“4.4.27 PF Roller Unit” (p164)
“4.4.22 Front Frame” (p158)
“4.4.17 CR Guide Frame” (p151)
“4.4.13 ASF Unit” (p146)
“4.4.14 Holder Shaft Unit” (p148)
“4.4.10 PS Board Unit” (p139)
“4.4.19 PF Motor” (p153)
“4.4.21 Paper Guide Upper Unit” (p157)
“4.4.7 Printhead” (p133)
“4.4.24 Ink System Unit” (p161)
“4.4.18 CR Motor” (p152)
“4.4.1 Document Cover/Document
Cover Mat/ ASF Cover” (p128)
“4.5.2 Scanner Carriage Unit” (p166)
“4.5.3 Scanner Motor Unit/Scanner HP Sensor/
Driven Pulley” (p168)
“4.4.11 Waste Ink Pads/Stacker Lock/PG
Lever/Rubber Feet” (p140)
“4.4.3 Stacker Assy.” (p129)
“4.5.1 Scanner Housing, Upper” (p165)
“4.4.5 Scanner Unit” (p131)
C H E C K
P O I N T
 As each parts in the Scanner Unit are not specified as ASP parts, disassembly procedures
for parts in the Scanner Unit are for referential purposes.
 Boxes shown in the dotted-line is not the shortest procedure, but is necessary to proceed
to the next step.
“4.4.2 Paper Support Assy.” (p129)
“4.4.4 Panel Unit” (p130)
“4.4.4 Panel Unit” (p130)
“4.4.8 CR Scale” (p135)
“4.4.23 EJ Frame Unit” (p159)
“4.4.23 EJ Frame Unit” (p159)
