EPSON Stylus CX4900/CX4905/CX5000/DX5000/DX5050/CX5900/CX6000/DX6000/DX6050 Revision A
APPENDIX Electrical Circuits 203
7.2 Electrical Circuits
The electric circuit diagrams below are shown at the following pages:
 C657
Main control circuit board
 C610
PSB/PSE power supply circuit board
 C571
*
1
/C657*
2
Panel circuit board
 C610
I/F circuit board
 C654
HEAD circuit board
Note *1: Stylus CX4900/CX4905/CX5000/DX5000/DX5050 only
*2: Stylus CX5900/CX6000/DX6000/DX6050 only
