EPSON Stylus CX4900/CX4905/CX5000/DX5000/DX5050/CX5900/CX6000/DX6000/DX6050 Revision A
PRODUCT DESCRIPTION Control Panel 49
1.9 Control Panel
1.9.1 Control Panel of Stylus CX4900/CX4905/CX5000/
DX5000/DX5050
Buttons
The control panel contains the following buttons, which are used to set and execute
vari
ous operations.
All of them are non-lock type buttons.
Note "*": Numbers in the table correspond to the numbers shown in Figure 1-22 (p50).
Note *1: B&W means “Black and White”.
Refer to “1.9.4.1 Stand-alone Copy / Memory Card Print (Stylus CX4900/CX4905/
CX5000/DX5000/DX5050)” (p.55) for details about each button.
Indicat
ors
The control panel contains 7-segment LED and 13 LEDs, which are used to indicate
variou
s status.
Note "*": Numbers in the table correspond to the numbers shown in Figure 1-22 (p50)
Note *1: All LEDs except for Power LED will be turned off while printing or scanning by PC.
*2: When DPOF printing is proceeding, this LED is blinking.
*3: When Memory Card Print mode is selected, those LEDs are turned off.
*4: Letter, when the LED is light. A4, when the LED is blinking.
*5: This LED is located near the card slot, not on the control panel.
Table 1-48. Buttons
Button * Function
Power 1
Execute turning on/off this unit.
Memory Card 2
Make transition from “Copy mode” to “Memory Card mode” and
selects one of card print mode.
Copy 3
Make transition from “Memory Card mode” to “Copy mode” and
sets number of copies.
Paper Type 4 Select paper type.
Paper Size 5 Select paper size.
Ink 6 Execute exchanging ink cartridges or head cleaning.
Fit to Page 7 Alternate zoom of “Fit to page” and default (actual; 100%).
B&W Start *
1
8 Start monochrome copy.
Color Start 9
Start card print or color copy.
Stop 10 Stop job of copying or printing or sometimes work as shift button.
Table 1-49. Indicators (Stylus CX4900/CX4905/CX5000/CX5050)
LED * Function
Power LED [Green] *
1
A Light at stand-by. Blink while some operation is proceeding.
Error LED [Red] B Light or blink while some error or warning is occurring.
Ink LED [Red] C
Light when some ink is out. Blink when some ink is near empty
or in the ink cartridge exchanging procedure.
Memory Card LED 1-3
D
Light one of them while some memory card print function
showing below is ready or proceeding.
1
st
[Green] Print Index Sheet
2
nd
[Green] Print From Index Sheet
3
rd
[Green] *
2
Print All / DPOF
7-seg. LED *
3
E
Indicate number of copies, or some error codes in error status.
Decimal Point
LE
D
Blinks slowly in low power panel status.
Paper Type LED 1,2
F
Light one of them showing which paper type below is selected.
1
st
[Green] Plain Paper
2
nd
[Green] Photo Paper
Paper Size LED 1-3
G
Light one of them showing
which paper size below is selected.
1
st
[Green] 10x15/ 4”x6”
(Euro/Asia), 4”x6” (EAI/Latin)
2
nd
[Green] 13x18/5”x7” (Euro/Asia), 5”x7” (EAI/Latin)
3
rd
[Green] A4 (Euro/Asia), Letter (EAI), Letter/A4 (Latin)*
4
Fit to Page LED
[Green]
H
Light when “Fit to Page” function is effective in copy mode.
Card Access LED
[Green] *
5
--
Light when available memory card is in a slot. Blink when
accessing to the card.
