EPSON Stylus CX4900/CX4905/CX5000/DX5000/DX5050/CX5900/CX6000/DX6000/DX6050 Revision A
APPENDIX Connector Summary 201
41 RESET Reset
42 /WAIT Bus cycle extension
43 INPACK Input port response
44 /REG Register select
45 BVD2/SPKA Battery voltage detect/audio digital waveform
46 BVD1/STSCHG Battery voltage detect/card status change
47 CD8
Data bus for CF slot (8)
48 CD9 Data bus for CF slot (9)
49 CD10 Data bus for CF slot (10)
50 GND — Ground
Table 7-15. CN15 - Memory Card
Pin Signal Name I/O Function
1 GND — Ground
2 BS Serial protocol bus state signal
3 MSD1 Memory Stick Data (Bit 1)
4 MSD0 Memory Stick Data (Bit 0)
5 MSD2 Memory Stick Data (Bit 2)
6 IN5 T.B.D.
7 MSD3 —
Memory Stick Data (Bit 3)
8 SCLK Stick inserted/removed detect terminal
9 VCC Power supply for Memory Stick
10 GND — Ground
X1 GND — Ground
X2 XD_ROY
X3 XD_OEB
X4 XD_CEB
X5 XD_CLE
X6 XD_ALE
X7 XD_WEV
Table 7-14. CN14 - Memory Card
Pin Signal Name I/O Function
X8 XD_WPB
X9 GND Ground
X10 XD_DO xD-Picture Card Data (Bit 0)
X11 XD_D1
xD-Picture Card Data (Bit 1)
X12 XD_D2 xD-Picture Card Data (Bit 2)
X13 XD_D3 xD-Picture Card Data (Bit 3)
X14 XD_D4 xD-Picture Card Data (Bit 4)
X15 XD_D5 xD-Picture Card Data (Bit 5)
X16 XD_D6 xD-Picture Card Data (Bit 6)
X17 XD_D7
xD-Picture Card Data (Bit 7)
X18 XD_VCC —
D1 CD/DAT3
D2 CMD
D3 GND Ground
D4 VDD
D5 CLK Clock
D6 GND Ground
D7 DAT0
D8 DAT1 —
D9 DAT-D0
S1 WP — Write Protect
S3 DETECT
S4 XD-CD1 —
Table 7-16. CN16-USB Host I/F Board
Pin Signal Name I/O Function
1 GND — Ground
2 D+ Bi-D USB D+ Signal
3 D- Bi-D
USB D- Signal
4 VBUS_IN — USB VBUS Input
Table 7-15. CN15 - Memory Card
Pin Signal Name I/O Function
