EPSON Stylus CX4900/CX4905/CX5000/DX5000/DX5050/CX5900/CX6000/DX6000/DX6050 Revision A
PRODUCT DESCRIPTION Memory Card Print 39
1.5.8.3 20-up
Figure 1-18. 20-up
Note *1: 4" x 6" size will be used for EAI models.
*2: Stylus CX5900/CX6000/DX6000/DX6050 only
*3: 10 x 15 size will be used for EMC/Asia, Pacific models.
1.5.8.4 30-up
Figure 1-19. 30-up
Note *1: 4" x 6" size will be used for EAI models.
*2: 10 x 15 size will be used for EMC/Asia, Pacific models.
Table 1-37. 20-up (unit: mm (inch))
Paper type A B C D E F G H I J K L
4" x 6" *
1
101.60
(4.00)
152.40
(6.00)
20.00
(0.79)
20.00
(0.79)
6.10
(0.24)
6.30
(0.25)
19.80
(0.78)
20.30
(0.80)
3.00
(0.12)
3.00
(0.12)
89.30
(3.52)
112.30
(4.42)
5" x 7" *
1
*
2
127.00
(5.00)
178.00
(7.00)
29.00
(1.14)
24.60
(0.97)
3.00
(0.12)
3.00
(0.12)
5.00
(0.20)
10.00
(0.39)
1.70
(0.07)
10.00
(0.39)
121.00
(4.76)
163.00
(6.42)
10 x 15 *
3
101.60 152.40 20.00 20.00 6.10 6.30 19.80 20.30 3.00 3.00 89.30 112.30
13 x 18 *
2
*
3
127.00 178.00 29.00 24.60 3.00 3.00 5.00 10.00 1.70 10.00 121.00 163.00
A
K
L
J
D
EF
G
H
B
J
J
J
C
II
I
Table 1-38. 30-up (unit: mm (inch))
Paper type A B C D E F G H I J
5" x 7"*
1
127.00
(5.00)
178.00
(7.00)
20.0
(0.79)
20.0
(0.79)
4.5
(0.18)
4.5
(0.18)
14.0
(0.55)
14.0
(0.55)
4.5
(0.18)
6.0
(0.24)
13 x 18*
2
127.00 128.00 20.0 20.0 4.5 4.5 14.0 14.0 4.5 6.0
D
E
F
G
H
C
B
A
I
J
