Run time group 9 [R.Ixx]
OPTIONAL OUTPUT SETTING
R.I01 - OUT 10 setting
This parameter is available when optional output circuitry is
fitted.
Upper display: Gr.9
Lower display: Ou.10
Range: OFF = Relay deenergized
On = Relay energized
For OUT 11 up to OUT 19, the instrument will show on the lower
display the related output and it is possible to perform the same
setting as above described.
R.I02 - All relays deenergization
This parameter is available when optional output circuitry is
fitted.
Upper display: Gr.9
Lower display: dEEn
Range: OFF = No action
On = All relays will be deenergized
