RUN TIME AND CONFIGURATION MODES
The hardware selection described in "Operative mode and
hardware lock" paragraph allows you to start one of the two
following operative modes:
- run time mode
- configuration mode.
At power up, the instrument starts in the same mode it was prior
to the power OFF.
General note about graphic symbols used for mnemonic
code visualization.
The instrument displays some characters with special symbols.
The following table shows the correspondence between the
symbols and the characters
symbol character
"
"k
"
"m
" "V
" "W
"
"Z
" "J
Keyboard description
MENU = is used to select a parameter group
FUNC = o when the instrument is in "normal display mode" it
changes the indication on the lower display (see
"display function").
o During parameter modification, it allows you to
memorize the new value of the selected parameter
and go to the next parameter (increasing order).
MAN = o when the instrument is in "normal display mode",
pushing MAN push-button for more than 1 s, it is
possible to enable or disable the manual function.
o During parameter modification, it allows you to scroll
back the parameters and groups without memoriz-
ing the new setting.
s = o During parameter modification, it allows you to
increase the value of the selected parameter
o During MANUAL mode, it allows you to increase the
output value.
