ero electronic MKC - OUT 3 Function - [C.E03]; Servomotor Type

CnF. 2
39
- OUT 2 function - [C.E02]
Range: nonE = Output not used
ñAin = Time proportional main control output
SECn = Time proportional secondary control output
ALr.2 = Alarm 2 output
Eun.2 = Event 2 output
- OUT 3 function - [C.E03]
When the option is not mounted the middle display will show
“no.Pr” (not present).
Range: nonE = Output not used
ñAin = Time proportional main control output
SECn = Time proportional secondary control output
ALr.3 = Alarm 3 output
Eun.3 = Event 3 output
ñC.Sñ = Servomotor control drive as main control output
SC.Sñ = Servomotor control drive as secondary control
output
- OUT 4 function - [C.E04]
Range: nonE = Output not used
ñAin = Time proportional main control output
SECn = Time proportional secondary control output
ALr.4 = Alarm 4 output
Eun.4 = Event 4 output
NOTES:
1) When option is not mounted the middle display will show
“no.Pr” (not present).
2) When servomotor control drive is hardware selected (see
"Output 3 and 4 selection" at pag. 20), the OUT 4 can be
used only as servomotor drive.
- Servomotor type - [C.E05]
This parameter will be available only when servomotor control
drive is configured (“CnF.2 - O3.Fn” [C.E03]= “ñC.Sñ” or
“SC.Sñ”).
Range: CLSd = Close loop type
NOTE: this selection is available only if
feedback circuitry is mounted and selected.
OPEn = Open loop type
