CnF. 3
48
- Secondary control output conditioning
- [C.F12]
This parameter will be available only when secondary control
output is configured.
Range: norñ = The control output is calculated by the PID
CñPL = The control output is complemented (100-PID
calculated value)
Ouic = The control output is conditioned to match a
“QUICK OPENING” flow characteristic
Eou = The control output is conditioned to match an
“EQUAL PERCENTAGE” flow characteristic
For more details see also NOTE about output conditioning at
page 43.
- Secondary control output in engineering unit
- [C.F13]
This parameter will be available only when secondary control
output is configured.
Range: nO = Scalable is not required
YES = Scalable is required
NOTE: This scaling allows to display the output value in
engineering units instead of in percent.
- Secondary control output decimal point
position - [C.F14]
This parameter will be available only when "S.SCL" ("Secondary
control output in engineering units" [C.F13]) is set to "YES".
Range:
----. = No decimal figure
---.- = One decimal figure.
--.-- = Two decimal figures.
