ero electronic MKC - Decimal Point Position; Square Root Extraction for Main Input

CnF. 1
33
- Decimal point position - [C.d03]
Ranges:
----. = no decimal figure
---.- = one decimal figure
--.-- = two decimal figures
-.--- = three decimal figures
NOTES:
1) For main input type 1 to 6, 15 and 30 only the "no decimal
figure" and "one decimal figure" are selectable, the input
range is limited within -199.9 and 999.9 and it acts as an input
type changement.
2) For main input type 7 to 14 and 16 to 29 this parameter is not
available.
3) For linear input types (from 31 to 38) all positions are
available.
- Square root extraction for main input- [C.d04]
Ranges: dIS = square root extraction disabled
Enb = square root extraction enabled
31 = Linear From 0 to 20 mA
32 = Linear From 4 to 20 mA
33 = Linear From 0 to 5 V
34 = Linear From 1 to 5 V
35 = Linear From 0 to 10 V
36 = Linear From 2 to 10 V
37 = Linear From 0 to 60 mV
38 = Linear From 12 to 60 mV
* For these ranges it is possible to select a read-out with one
decimal figure but the instrument could not display a measure
lower than -199.9 or higher than 999.9 and the input range
will be limited by it.
NOTES:
1) When a linear input is selected, the instrument set automati-
cally the "readout initial scale value" [C.d05] equal to 0 and
the "readout final scale value" [C.d06] equal to 4000
2) When input type has been changed, the instrument
automatically forces:
- the "ñ.In.L" [C.d05], "SS.th" [C.I09] and "brG.L" [C.I03]
parameters to the new initial scale value,
- the "ñ.In.H" [C.d06] and "brG.H" [C.I04] parameter to the
new final scale value and
- the "ñ.In.d" [C.d03] parameter to "no decimal figure".
