ero electronic MKC - Out Failure Detection (OFD) - [C.I11]

CnF. 6
62
- Time out selection - [C.I10]
Range: tñ.10 = 10s time out
tñ.30 = 30s time out
NOTE: for more details see "NOTE 2" at page 26.
- Out failure detection (OFD) - [C.I11]
This parameter will be available only when the option is fitted
and the main and/or the secondary output is configured as time
proportional control output
Range: nonE = Function not provided
ñC.On = Set “Fd.Fn” to “ñC.On” when the load under test
is energized during the ON status of the main
output (relay energized or SSR output status 1).
ñC.OF= Set “Fd.Fn” to “ñC.OF” when the load under
test is energized during the OFF status of the
main output (relay de-energized or SSR output
status 0).
SC.On= Set “Fd.Fn” to “SC.On” when the load under test
is energized during the ON status of the second-
ary output (relay energized or SSR output status
1).
SC.OF= Set “Fd.Fn” to “SC.OF” when the load under test
is energized during the OFF status of the second-
ary output (relay de-energized or SSR output
status 0).
NOTE: When the option is not fitted the middle display will show
“no.Pr”
- Primary current of the current transformer
- [C.I12]
This parameter will be available only when “Fd.Fn” [C.I11] is
different from “nonE”
Range: From 10 A to 100 A
