ero electronic MKC - Out Failure Detection - Output Assignment

CnF. 7
63
- Out failure detection - output assignment
- [C.I13]
This parameter will be available only when “Fd.Fn” [C.I11] is
different from “nonE”
Range: nonE = The "Out failure detection" alarm is signalled
only on display
OUt.1 = The "Out failure detection" alarm is signalled
on OUT 1
OUt.2 = The "Out failure detection" alarm is signalled on
OUT 2
OUt.3 = The "Out failure detection" alarm is signalled on
OUT 3
OUt.4 = The "Out failure detection" alarm is signalled on
OUT 4
NOTE: "Out failure detection "alarm annunciator cannot be
assigned to an output just configured as control output.
CONFIGURATION GROUP 7 [C.Lxx]
INPUT/OUTPUT TEST
This group is displayed only when configuration modify mode is
enabled.
This group allows you to verify the correct working of:
- the relay outputs (OUT 1 up to OUT4),
- digital inputs (diG.1 up to diG.3),
- the inputs from In1 up to In8 and the relays of the outputs from
OUT10 up to OUT19, if the optional I/O card is fitted.
When an output is in "On" status, the related LED will light up
