CnF. 6
60
- Bargraph initial scale value - [C.I03]
This parameter will be available only for MKC models when
“G.brG” [C.I01] is equal to “Pr.Ur” and/or “O.brG” [C.I02] is equal
to “OP.SP”.
Range: From “ñ.In.L” ("Read-out initial scale value" [C.d05]) to
“ñ.In.H” ("Read-out full scale value [C.d06])
- Bargraph full scale value - [C.I04]
This parameter will be available only for MKC models when
“G.brG” [C.I01] is equal to “Pr.Ur” and/or “O.brG” [C.I02] is equal
to “OP.SP”.
Range: From “ñ.In.L” ("Read-out initial scale value" [C.d05]) to
“ñ.In.H” ("Read-out full scale value [C.d06])
- Resolution of the deviation bargraph - [C.I05]
This parameter will be available only for MKC models when
“G.brG” [C.I01] is equal to “DEV.”.
Range: 1-2-5-10-20 or 50 = Digits per segment
- Operative set point alignment at start up
- [C.I06]
Range: ALG = At start up the operative set point is aligned to
measure value and then it will reach the
selected set point with the programmed ramp
(“Grd1” [r.E14] and “Grd2” [r.E15]).
n.ALG = At start up the operative set point is equal to the
selected set point
NOTE:The “ALG” selection has no effect when the measure is in
error condition or Remote Set point is selected.
