ero electronic MKC - Secondary Control Output Initial Scale Value; Secondary Control Output Full Scale Value; Secondary Output Auxiliary Conditioning

CnF. 3
49
- Secondary control output initial scale value
- [C.F15]
This parameter will be available only when "S.SCL" ("Secondary
control output in engineering units" [C.F13]) is set to "YES".
Range: from -199 to 999
- Secondary control output full scale value
- [C.F16]
This parameter will be available only when "S.SCL" ("Secondary
control output in engineering units" [C.F13]) is set to "YES".
Range: From -199 to 999
- Secondary output auxiliary conditioning
- [C.F17]
This parameter will be available only when secondary control
output is configured and “SC.Cn” ("Secondary control output
conditioning" [C.F12]) is different from “norñ”.
Range: bEFr = The functions listed at Note (**) are calculated
before to apply the action selected by “SC.Cn”
("Secondary control output conditioning"
[C.F12]) parameter.
AFtr = The functions listed at Note (**) are calculated
after to apply the action selected by “SC.Cn”
(“Secondary control output conditioning”
[C.F12]) parameter.
General note on configuration group 3
Exiting from the configuration group 3 the instrument automati-
cally tests the "SPLt" parameter (Split range [C.F01]). When
"SPLt." parameter is enabled (= "Enb"), the instrument performs
the following actions:
1) If “Añ.UL” parameter ("Output value for AUTO to MAN
transfer [C.G04]) is lower than 0, it will be forced to “buñ“.
2) If the “SF.UL” parameter ("Output safety value" [C.G08]) is
lower than zero, it will be forced to zero.
3) If the “IP” parameter ("Integral pre-load" [r.d05] is lower than
zero, it will be forced to 50.0.
Xkc-1-C0.P65 5/29/02, 11:59 AM49
